TDK压敏电阻B72660M0271K072 130V 1200A 200pF Varistor
价格：￥
联系人：万小姐、龚先生、周小姐，肖小姐，张小姐，程先生 联系电话：0755-83722245,0755-28194352,075528193653,28197027分机806,83722245,29806019,0791-86663634,0791-86227604
产品保证货真价实诚实守信
CU3225K11G2 B72650M0110K072 11 14 100 300 10
CU4032K11G2 B72660M0110K072 11 14 250 800 20
CU3225K14G2 B72650M0140K072 14 18 100 400 10
CU4032K14G2 B72660M0140K072 14 18 250 900 20
CU3225K17G2 B72650M0170K072 17 22 100 500 10
CU4032K17G2 B72660M0170K072 17 22 250 1100 20
CU3225K20G2 B72650M0200K072 20 26 100 600 10
CU4032K20G2 B72660M0200K072 20 26 250 1300 20
CU3225K25G2 B72650M0250K072 25 31 100 700 10
CU4032K25G2 B72660M0250K072 25 31 250 1600 20
CU3225K30G2 B72650M0300K072 30 38 100 900 10
CU4032K30G2 B72660M0300K072 30 38 250 2000 20
CU3225K35G2 B72650M0350K072 35 45 100 1100 10
CU4032K35G2 B72660M0350K072 35 45 250 2500 20
CU3225K40G2 B72650M0400K072 40 56 100 1300 10
CU4032K40G2 B72660M0400K072 40 56 250 3000 20
CU3225K50G2 B72650M0500K072 50 65 400 1800 100
CU4032K50G2 B72660M0500K072 50 65 1200 4200 250
CU3225K60G2 B72650M0600K072 60 85 400 2200 100
CU4032K60G2 B72660M0600K072 60 85 1200 4800 250
CU3225K75G2 B72650M0750K072 75 100 400 2500 100
CU4032K75G2 B72660M0750K072 75 100 1200 5900 250
CU3225K95G2 B72650M0950K072 95 125 400 3400 100
CU4032K95G2 B72660M0950K072 95 125 1200 7600 250
CU3225K115G2 B72650M0111K072 115 150 400 3600 100
CU4032K115G2 B72660M0111K072 115 150 1200 8400 250
CU3225K130G2 B72650M0131K072 130 170 400 4200 100
CU4032K130G2 B72660M0131K072 130 170 1200 9500 250
CU3225K140G2 B72650M0141K072 140 180 400 4500 100
CU4032K140G2 B72660M0141K072 140 180 1200 10000 250
CU3225K150G2 B72650M0151K072 150 200 400 4900 100
CU4032K150G2 B72660M0151K072 150 200 1200 11000 250
CU3225K175G2 B72650M0171K072 175 225 400 5600 100
CU4032K175G2 B72660M0171K072 175 225 1200 13000 250
CU3225K11G2 18 ±10 36 1 1750
CU4032K11G2 18 ±10 36 2.5 2750
CU3225K14G2 22 ±10 43 1 1450
CU4032K14G2 22 ±10 43 2.5 2300
CU3225K17G2 27 ±10 53 1 1200
CU4032K17G2 27 ±10 53 2.5 1900
CU3225K20G2 33 ±10 65 1 980
CU4032K20G2 33 ±10 65 2.5 1600
CU3225K25G2 39 ±10 77 1 850
CU4032K25G2 39 ±10 77 2.5 1400
CU3225K30G2 47 ±10 93 1 720
CU4032K30G2 47 ±10 93 2.5 1200
CU3225K35G2 56 ±10 110 1 620
CU4032K35G2 56 ±10 110 2.5 1050
CU3225K40G2 68 ±10 135 1 520
CU4032K40G2 68 ±10 135 2.5 900
CU3225K50G2 82 ±10 135 5 300
CU4032K50G2 82 ±10 135 10 530
CU3225K60G2 100 ±10 165 5 250
CU4032K60G2 100 ±10 165 10 480
CU3225K75G2 120 ±10 200 5 210
CU4032K75G2 120 ±10 200 10 430
CU3225K95G2 150 ±10 250 5 135
CU4032K95G2 150 ±10 250 10 260
CU3225K115G2 180 ±10 300 5 110
CU4032K115G2 180 ±10 300 10 220
CU3225K130G2 205 ±10 340 5 100
CU4032K130G2 205 ±10 340 10 200
CU3225K140G2 220 ±10 360 5 95
CU4032K140G2 220 ±10 360 10 180
CU3225K150G2 240 ±10 395 5 90
CU4032K150G2 240 ±10 395 10 170
CU3225K175G2 270 ±10 455 5 75
CU4032K175G2 270 ±10 455 10 1
CU3225K250G2 B72650M0251K072 250 320 400 8200 100
CU4032K250G2 B72660M0251K072 250 320 1200 19000 250
CU3225K275G2 B72650M0271K072 275 350 400 8600 100
CU4032K275G2 B72660M0271K072 275 350 1200 21000 250
CU3225K300G2 B72650M0301K072 300 385 400 9600 100
CU4032K300G2 B72660M0301K072 300 385 1200 23000 250
Characteristics (TA = 25 °C)
Type VV
(1 mA)
V
∆VV
%
Vclamp,max
V
Iclamp
(8/20 μs)
A
Ctyp
(1 kHz, 1 V)
pF
CU3225K250G2 390 ±10 650 5 55
CU4032K250G2 390 ±10 650 10 105
CU3225K275G2 430 ±10 710 5 50
CU4032K275G2 430 ±10 710 10 95
CU3225K300G2 470 ±10 775 5 45
CU4032K300G2 470 ±10 775 10 90
3225 Blister 330 1000 CU3225K115G2 B72650M0111K072
3225 Blister 330 1000 CU3225K11G2 B72650M0110K072
3225 Blister 330 1000 CU3225K130G2 B72650M0131K072
3225 Blister 330 1000 CU3225K140G2 B72650M0141K072
3225 Blister 330 1000 CU3225K14G2 B72650M0140K072
3225 Blister 330 1000 CU3225K150G2 B72650M0151K072
3225 Blister 330 1000 CU3225K175G2 B72650M0171K072
3225 Blister 330 1000 CU3225K20G2 B72650M0200K072
3225 Blister 330 1000 CU3225K230G2 B72650M0231K072
3225 Blister 330 1000 CU3225K250G2 B72650M0251K072
3225 Blister 330 1000 CU3225K25G2 B72650M0250K072
3225 Blister 330 1000 CU3225K275G2 B72650M0271K072
3225 Blister 330 1000 CU3225K300G2 B72650M0301K072
3225 Blister 330 1000 CU3225K30G2 B72650M0300K072
3225 Blister 330 1000 CU3225K35G2 B72650M0350K072
3225 Blister 330 1000 CU3225K40G2 B72650M0400K072
3225 Blister 330 1000 CU3225K50G2 B72650M0500K072
3225 Blister 330 1000 CU3225K60G2 B72650M0600K072
3225 Blister 330 1000 CU3225K75G2 B72650M0750K072
3225 Blister 330 1000 CU3225K95G2 B72650M0950K072
3225 Blister 330 1000 CU4032K11G2 B72660M0110K072
4032 Blister 330 1000 CU3225K17G2 B72650M0170K072
4032 Blister 330 1000 CU4032K115G2 B72660M0111K072
4032 Blister 330 1000 CU4032K130G2 B72660M0131K072
4032 Blister 330 1000 CU4032K140G2 B72660M0141K072
4032 Blister 330 1000 CU4032K14G2 B72660M0140K072
4032 Blister 330 1000 CU4032K150G2 B72660M0151K072
4032 Blister 330 1000 CU4032K175G2 B72660M0171K072
4032 Blister 330 1000 CU4032K17G2 B72660M0170K072
4032 Blister 330 1000 CU4032K20G2 B72660M0200K072
4032 Blister 330 1000 CU4032K230G2 B72660M0231K072
4032 Blister 330 1000 CU4032K250G2 B72660M0251K072
4032 Blister 330 1000 CU4032K25G2 B72660M0250K072
4032 Blister 330 1000 CU4032K275G2 B72660M0271K072
4032 Blister 330 1000 CU4032K300G2 B72660M0301K072
4032 Blister 330 1000 CU4032K30G2 B72660M0300K072
4032 Blister 330 1000 CU4032K35G2 B72660M0350K072
4032 Blister 330 1000 CU4032K40G2 B72660M0400K072
4032 Blister 330 1000 CU4032K50G2 B72660M0500K072
4032 Blister 330 1000 CU4032K60G2 B72660M0600K072
4032 Blister 330 1000 CU4032K75G2 B72660M0750K072
4032 Blister 330 1000 CU4032K95G2 B72660M0950K072
EPCOS:
B72650M0251K072 B72650M0600K072 B72660M0131K072 B72660M0251K072 B72660M0300K072
B72650M131K72 B72650M171K72 B72650M271K72 B72650M301K72 B72660M271K72
