Part Status Active

Connector Type Header

Contact Type Male Pin

Pitch - Mating 0.100" (2.54mm)

Number of Positions 40

Number of Rows 2

Row Spacing - Mating 0.100" (2.54mm)

Number of Positions Loaded All

Style Board to Board or Cable

Shrouding Shrouded - 4 Wall

Mounting Type Surface Mount

Termination Solder

Fastening Type Push-Pull

Contact Length - Mating -

Contact Length - Post -

Overall Contact Length -

Insulation Height 0.358" (9.10mm)

Contact Shape Square

Contact Finish - Mating Gold

Contact Finish Thickness - Mating Flash

Contact Finish - Post Gold

Contact Material Brass

Insulation Material Polyamide (PA), Nylon

Features Keying Slot

Operating Temperature -40¡ãC ~ 105¡ãC

Ingress Protection -

Material Flammability Rating UL94 V-0

Insulation Color Black

Current Rating 3A

Voltage Rating -

Mated Stacking Heights 11.17mm, 12.72mm, 14.87mm, 19.87mm

Contact Finish Thickness - Post Flash
