Gumstix Poblano 43C Handheld Development Kit

Gumstix Poblano 43C Handheld Development Kit is a complete hardware platformed designed to be usable as the base for a handheld, touchscreen-based application. This Handheld Development Kit is based on the Gumstix Wi-Fi® and Bluetooth® enabled Poblano 43C Single Board Computer, running Yocto Project Linux® and Android™. The Handheld Development Kit also includes a 4.3" Newhaven LCD Capacitive Touchscreen, a 5V power adapter, antenna, Ethernet cable, and USB cable. The supported boot images of Yocto Project Linux and Android are provided on separate microSD cards for convenience.

DOCUMENTS

• Datasheet

• Technical Reference

FEATURES

• Poblano 43C Single Board Computer

• 5V power connector

• 6mm rechargeable coin cell battery holder

• IEEE 802.11b, 802.11g, 802.11n

• Bluetooth 4.1+BLE (Bluetooth Low Energy)

• Texas Instruments Sitara AM4378 Arm® Cortex™-A9 Microcontroller

• Texas Instruments WiLink™8 Wi-Fi®, Bluetooth®, and Bluetooth Smart Module

• Display Support: Capacitive Touchscreen

• FTDI FT232RQ USB UART Interface

• Texas Instruments TPS65218 Power Management IC

• 8GB Embedded NAND Flash Storage

• U.FL Antenna connector

• microSD Card Slot

• USB A ports (2)

• USB micro B port

• 10/100/1000 Base-T Ethernet port

• Hirose 40-position FPC/FFC connector

• Hirose 27-pin camera connector

• GPIO-controlled push buttons and LEDs

• Power Options

• Newhaven 4.3 Capacitive or Resistive Touchscreen

• 480px x 272px resolution

• 6:00 optimum viewing angle

• 3.3V

• 24-bit parallel RGB interface

• White LED backlight

• RoHS compliant

• microSD Cards with Yocto Project Linux and Android boot images

• U.FL Antenna

• USB A to micro B Cable

• Ethernet Cable

• 5V, 3.5A Power Adapter (USA)

ASSOCIATED PRODUCTS

• Texas Instruments AM437x Sitara™ ARM® Cortex-A9 Processors

• Texas Instruments WL18xxMOD WiLink™ Single Band Combo Modules

• FTDI FT232RQ USB UART Interface

• Texas Instruments TPS65218 Power Management IC (PMIC)
