Gumstix Pepper 43 Handheld Development Kits

Gumstix Pepper 43 Handheld Development Kits are complete hardware packages designed to get developers started with a handheld, touchscreen-based application. These Handheld Development Kits are based on Gumstix Wi-Fi® and Bluetooth® enabled Pepper 43 Single Board Computers, running Yocto Project Linux® and Android™. The Handheld Development Kits also include a 4.3" Newhaven LCD Capacitive or Resistive LCD Touchscreen, a 5V power adapter, antenna, Ethernet cable, and USB cable. The supported boot images of Yocto Project Linux and Android are provided on separate microSD cards for convenience.

DOCUMENTS

• Pepper 43C Handheld Development Kit (KIT30003) - Datasheet

• Pepper 43R Handheld Development Kit (KIT30004) - Datasheet

• Pepper 43R Single Board Computer - Technical Reference

• Newhaven 4.3" Capacitive Touchscreen - Datasheet

• Newhaven 4.3" Resistive Touchscreen - Datasheet

FEATURES

• Pepper 43C or Pepper 43R Single Board Computer

• 5V barrel connector

• 6mm rechargeable coin cell battery holder

• IEEE 802.11b, 802.11g, 802.11n

• Bluetooth 4.1+BLE (Bluetooth Low Energy)

• Texas Instruments 800Mhz Sitara AM3354 Arm® Cortex™-A8 Microcontroller

• Texas Instruments WiLink™8 Wi-Fi®, Bluetooth®, and Bluetooth Smart Module


• FTDI FT232RQ USB UART Interface

• Texas Instruments TPS65217DRSLR Power Management IC

• Texas Instruments TPS62111 DC-DC Step Down Converter

• DDR3L 512MB 16bit

• U.FL Antenna connector

• microSD Card Slot

• USB A ports (2)

• USB micro B port

• 10/100/1000 Base-T Ethernet port

• Hirose 40-position FPC/FFC connector

• Hirose 27-pin camera connector

• GPIO-controlled push buttons and LEDs

• Power Options

• Newhaven 4.3 Capacitive or Resistive Touchscreen

• 480px x 272px resolution

• 6:00 optimum viewing angle

• 3.3V

• 24-bit parallel RGB interface

• White LED backlight

• RoHS compliant

• microSD Cards with Yocto Project Linux and Android boot images

• U.FL Antenna

• USB A to micro B Cable

• Ethernet Cable

• 5V, 3.5A Power Adapter (USA)

KIT30004

KIT30003
