Mill-Max Low-Profile Interconnect Sockets

Mill-Max Low-Profile Interconnect Sockets are reliable, compact sockets for minimizing interconnect height. These super low-profile sockets feature an above-board height of just 2.11mm (.083"), providing a convenient way of connecting boards or devices. These Mill-Max sockets are ideal for medical wearables and implantable devices and come in single- and double-row versions.

FEATURES

• Super low profile, single- and double-row strips

• Series 315 and 415 solder mount sockets use MM #0512 receptacles that accept pin diameters from .015¡±-.022¡±

• Hi-Rel, 4-finger BeCu #12 contact is rated at 3A

• .083¡± Super low profile above the board utilizes .050¡± thick insulators

• Insulators are high temperature thermoplastic, suitable for all soldering operations
