CMOSIS/ams CMV2000 Image Sensors

CMOSIS/ams CMV2000 Image Sensors are high sensitivity, pipelined global shutter CMOS image sensors with 2048 x 1088 pixel resolution capable of HD format. The sensors are available in monochrome, color and near-infrared (NIR) enhanced versions. Pipelining allows exposure during read out.

The state-of-the-art pixel architecture offers true correlated double sampling (CDS) significantlyreducing the fixed pattern noise and dark noise. The image sensor integrates 16 LVDS channels each running at 480Mbps resulting in a 340fps frame rate at full resolution at 10-bit per pixel.

Programming of the image sensor is accomplished over a serial peripheral interface. An internal timing generator produces the signals needed for read-out and exposure control of the image sensor. External exposure triggering remains possible. A 12-bit per pixel mode is available at a reduced frame rate.

CMV2000 Eval Kit

CMV2000-2E12M1PP

CMV2000-2E5M1PP

CMV2000-3E12M1CA

CMV2000-3E12M1LP

CMV2000-3E12M1PA

CMV2000-3E12M1PN

CMV2000-3E12M1PP

CMV2000-3E5C1CA

CMV2000-3E5C1PA

CMV2000-3E5C1PN

CMV2000-3E5C1PP

CMV2000-3E5M1CA

CMV2000-3E5M1LP

CMV2000-3E5M1PA

CMV2000-3E5M1PP

CMV2K/4K-EVAL2
