74479628 Wurth 原装进口
Dimensions
| Size | L (mm) | W (mm) | H (mm) | Mount |
|---|---|---|---|---|
| 0603 | 1.6 | 0.8 | 0.8 | SMT |
| 0805 | 2.0 | 1.2 | – | SMT |
| 1206 | 3.2 | 1.6 | 1.1 | SMT |
Characteristics
Smallest inductor possible for less space needed on the print
WE-MI SMT Multilayer Inductor
ed circuit board and therefore perfect suitable for high density mounting
No cross coupling because of closed magnetic circuits
No crosstalk
Operating temperature: –55 °C to +125 °C
Applications
Filter switches
Oscillators
Adjustment networks
Discretely built T- or π-Filter
Products
0603
0805
1206
show full screen
| SPEC | Order Code | L1 (µH) | Qmin. | IR 1 (mA) | RDC1 max. (Ω) | Design Kit | Samples |
|---|---|---|---|---|---|---|---|
| 74479614 | 0.047 | 10 | 50 | 0.25 | 744790 | ||
| 74479616 | 0.068 | 10 | 50 | 0.25 | |||
| 7447962 | 0.1 | 15 | 50 | 0.5 | 744790 | ||
| 74479623 | 0.22 | 15 | 50 | 0.8 | 744790 | ||
| 744796233 | 0.33 | 15 | 35 | 0.8 | |||
| 74479632 | 0.47 | 15 | 35 | 1 | 744790 | ||
| 74479645 | 0.56 | 15 | 35 | 1.55 | 744790 | ||
| 7447964 | 0.68 | 15 | 35 | 1.7 | |||
| 74479628 | 0.82 | 15 | 35 | 2.1 | |||
| 7447965 | 1 | 35 | 25 | 0.6 | 744790 | ||
| 744796215 | 1.5 | 35 | 25 | 0.8 | |||
| 74479651 | 1.8 | 35 | 25 | 0.8 | |||
| 74479652 | 2.2 | 35 | 15 | 1 | 744790 | ||
| 74479653 | 3.3 | 35 | 15 | 1.4 | 744790 | ||
| 7447966 | 4.7 | 35 | 15 | 1.8 | 744790 | ||
| 74479668 | 6.8 | 35 | 5 | 1.7 | 744790 | ||
| 7447967 | 8.2 | 35 | 5 | 2.1 | 744790 | ||
| 7447968 | 10 | 30 | 3 | 1.85 | 744790 |
