【正！品！TE Connectivity开关原装进口】GDS10S04 SMT 1-1825006-9
Product key Positions Mounting Packaging Part number
GDS0204 2 THT tube 1825006-1
GDS02S04 SMT 1825006-3
GDS02STR04 tape and reel 1825006-4
GDS0404 4 THT tube 1825006-5
GDS04S04 SMT 1825006-7
GDS04STR04 tape and reel 1825006-8
GDS0604 6 THT tube 1825006-9
GDS06S04 SMT 1-1825006-1
GDS06STR04 tape and reel 1-1825006-2
GDS0804 8 THT tube 1-1825006-3
GDS08S04 SMT 1-1825006-5
GDS08STR04 tape and reel 1-1825006-6
GDS1004 10 THT tube 1-1825006-7
GDS10S04 SMT 1-1825006-9
GDS10STR04 tape and reel 2-1825006-0
Product key Positions Mounting Packaging Part number
GDP0204 2 THT tube 1571998-1
GDP02STR04 SMT tape and reel 1571998-4
GDP0404 4 THT tube 1571998-5
GDP04STR04 SMT tape and reel 1571998-8
GDP0604 6 THT tube 1571998-9
GDP06STR04 SMT tape and reel 1-1571998-2
GDP0804 8 THT tube 1-1571998-3
GDP08STR04 SMT tape and reel 1-1571998-6
GDP1004 10 THT tube 1-1571998-7
GDP10STR04 SMT tape and reel 2-1571998-0
Product key Positions Mounting Packaging Part number
GDR0404 4 THT tube 1825286-3
GDR04S04 SMT 1825286-4
GDR0804 8 THT 1825286-7
GDR08S04 SMT 1825286-8
Product key Positions Mounting Packaging Part number
GDH02S04 2 SMT tube 1571983-1
GDH02STR04 tape and reel 1571983-3
GDH04S04 4 tube 1571983-4
GDH04STR04 tape and reel 1571983-5
GDH06STR04 6 1571983-9
GDH08S04 tube 1-1571983-0
GDH08STR04 8 tape and reel 1-1571983-1
Product key Positions Mounting Packaging Part number
GDHL04S 4 SMT tube 1977103-3
GDHL04STR tape and reel 1977103-4
GDHL08S 8 tube 1977103-7
GDHL08STR tape and reel 1977103-8
Product key Positions Mounting Packaging Part number
ADE0204 2 THT tube 1825057-1
ADE0404 4 1825057-3
ADE04S04 SMT 1825058-7
ADE0604 6 THT 1825057-5
ADE0804 8 1825057-7
ADE08S04 SMT 1-1825058-9
ADE1004 10 THT 1825057-9
Product key Positions Mounting Packaging Part number
ADF flush actuator
ADF0204 2 THT tube 1825002-1
ADF0404 4 1825002-5
ADF0604 6 1825002-9
ADF0804 8 1-1825002-3
ADF1004 10 1-1825002-7
ADF flush actuator with seal tape
ADF02STTR04 2 SMT tape and reel 1825059-6
ADF04STTR04 4 1-1825059-8
ADF06STTR04 6 3-1825059-0
ADF08STTR04 8 4-1825059-2
ADF10STTR04 10 5-1825059-4Catalogue No. 1308111
Issued 03/2008
Dimensions are in mm and are shown
for reference purposes only.
Specifications subject to change. www.tycoelectronics.com
Switches
15
Preferred Part Numbers - DIP Switches, DIP Shunts, Rotary (Continued)
ADP Series
STV, STR Series
DIP Series
HTH DIP Shunts
DIP-Fix
MRD Series
DR-/D/M/S/W Series
Product key Positions Mounting Packaging Part number
ADP0204 2 THT tube 1571999-1
ADP02STR04 SMT tape and reel 1571999-4
ADP0404 4 THT tube 1571999-6
ADP04STR04 SMT tape and reel 1571999-9
ADP0604 6 THT tube 1-1571999-6
ADP06STR04 SMT tape and reel 1-1571999-9
ADP0804 8 THT tube 2-1571999-6
ADP08STR04 SMT tape and reel 2-1571999-9
ADP1004 10 THT tube 3-1571999-6
ADP10STR04 SMT tape and reel 3-1571999-9
STV04 4 THT, vertical tube 1977104-2
STV08 8 1977104-4
STR04 4 THT, horizontal 1977105-2
STR08 8 1977105-4
Product key Positions Mounting Packaging Part number
HTH04 4 THT tube 1825190-3
HTH08 8 1825190-7
Product key Positions Mounting Packaging Part number
MRD1004 10/BCD THT tube 1825013-1
MRD10STR04 SMT tape and reel 1-1825013-1
MRD10CSTR04 10/BCD compl. 1825013-6
MRD1604 16/Hex THT tube 1-1825013-1
MRD16STR04 SMT tape and reel 2-1825013-0
MRD16CSTR04 16/Hex compl. 1-1825013-6
Product key Positions Mounting Packaging Part number
DRD10CE04 10/BCD compl. THT tube 1825007-1
DRD10E04 10/BCD 1825007-6
DRD10SETR04 SMT tape and reel 1-1825007-0
DRD16CE04 16/Hex compl. THT tube 1-1825007-1
DRD16E04 16/Hex 1-1825007-6
DRD16SETR04 SMT tape and reel 2-1825007-0
DRM10RA04 10/BCD THT tube 1825008-6
DRM16RA04 16/Hex 1825008-8
Product key Positions Mounting Packaging Part number
DIP01 1 THT tube 5161390-1
DIP02 2 5161390-2
DIP03 3 5161390-3
DIP04 4 5161390-4
DIP05 5 5161390-5
DIP08 8 5161390-8
Product key Positions Mounting Packaging Part number
DIP-FIX-A104 4 THT trays 1393546-4
DIP-FIX-A108 8 1393546-8
DIP-FIX-A124 24 1-1393546-3
DIP-FIX-A201 1 changeover 1-1393546-4
DIP-FIX-A202 2 changeover 1-1393546-5
DIP-FIX-A204 4 changeover 1-1393546-7
DIP-FIX-A212 12 changeover 2-1393546-0
FSM2L 1.3 N 5 mm THT bulk 1825965-1
FSM1L 4.3 mm 1825966-1
FSM1SM 1.8 N SMT 1437566-3
FSM1SMTR tape and reel 1437566-4
FSM1JMTR 4.3 mm SMT/J 147873-2
FSM2JMTR 5 mm 147873-1
FSM SM/JM S, Sealed
FSM2S 1.3 N 5 mm THT bulk 1571297-1
FSM2SSMTR SMT tape and reel 1571298-2
FSM1SJMTR 4.3 mm SMT/J 1571299-2
FSM2SJMTR 5 mm 1571299-4
Product key Act. Force Height Mounting Packaging Part number
FSMJMLPTR 1.6 N 2.5 mm SMT/J tape and reel 1571528-1
FSMJMLPATR 2.6 N 1571528-2
FSMSMLPTR 1.6 N SMT 1825086-1
FSMSMLPATR 2.6 N 1825086-2
FSM2JH 1.6 N 4.3 mm THT bulk 1825910-2
FSM2JAH 2.6 N 1825910-3
FSMCD, Square Button
FSMCD1H 1.6 N 7.5mm,A2.42mm THT bulk 1825967-1
FSMCD2H 7.5mm,A2.8mm 1825967-2
FSMRACD, Square Button, Right Angle
FSMRACD1H 1.6 N 6.35mm,A2.42mm THT bulk 1825968-1
FSMRACD2H 6.35mm,A2.8mm 1825968-2
FSMJSM, SMT Mounting
FSM2JSMLS 1.0 N 4.3 mm SMT bulk 1977223-1
FSM2JSMLSTR tape and reel 1977223-2
FSM2JSMAS 1.6 N bulk 1977223-3
FSM2JSMASTR tape and reel 1977223-4
FSM2JSMAAS 2.6 N bulk 1977223-5
FSM2JSMAASTR tape and reel 1977223-6
FSM4JSMXLS 0.7 N 5 mm bulk 1-1977223-3
FSM4JSMXLSTR tape and reel 1-1977223-4
FSM4JSMAS 1.6 N bulk 1977223-9
FSM4JSMASTR tape and reel 1-1977223-0
FSM4JSMAAS 2.6 N bulk 1-1977223-1
FSM4JSMAASTR tape and reel 1-1977223-2
FSM6JSMAS 1.6 N 7 mm bulk 1-1977223-7
FSM6JSMASTR tape and reel 1-1977223-8
FSM6JSMAAS 2.6 N bulk 1-1977223-9
FSM6JSMAASTR tape and reel 2-1977223-0
FSMJEL, Extendet Life, J-Lead
FSM2JELJ 1.6 N 2.5 mm SMT/J bulk 1571625-5
FSM2JELJTR tape and reel 1571625-6
FSMJEL, Extendet Life, Gull Wing
FSM2JELG 1.6 N 2.5 mm SMT/G bulk 1571626-5
FSM2JELGTR tape and reel 1571626-6
FSMJEL, Extendet Life, Gull Wing, Ground Terminal
FSM2JELGE 1.6 N 2.5 mm SMT/G bulk 1571636-5
FSM2JELGETR tape and reel 1571636-6
FSM1LP, Low Profile
FSM1LPS 1.6 N 3.09 mm SMT bulk 1977263-1
FSM1LPSTR tape and reel 1977263-2
FSM1LPAS 2.6 N bulk 1977263-3
FSM1LPASTR tape and reel 1977263-4
FSMJS, Sealed 7.6 mm
FSM1JSSM 1.6 N 3.3 mm SMT bulk 1571296-1
FSM1JSSMTR tape and reel 1571296-2
FSM2JS 4.3 mm THT bulk 1571295-1
FSM2JSSM SMT 1571294-1
FSM2JSSMTR tape and reel 1571294-2
FSM4JS 5 mm THT bulk 1571295-2
FSM4JSSM SMT 1571294-3
FSM4JSSMTR tape and reel 1571294-4
FSMJS, Sealed 6 mm
FSM1JS6 1.6 N 4,3 mm THT bulk 1977121-1
FSM2JS6SM SMT 1977265-1
FSM2JS6SMTR tape and reel 1977265-2
FSMRAJS, Sealed Right Angle
FSMRAJS1SM 2.6 N SMT bulk 1571407-1
FSMRAJS1SMTR tape and reel 1571407-2
FSMRAJ, Right Angle Shaft length
FSMRA1JH 1.6 N 0.55 mm THT bulk 1825027-2
FSMRA2JH 1.25 mm 1825027-5
FSMRA3JH 3.25 mm 1825027-8
FSMRA4JH 5.74 mm 1-1825027-1
FSMRA5JH 3.55 mm 1-1825027-4
FSMRA6JH 4.25 mm 1-1825027-7
FSMRA7JH 9.25 mm 2-1825027-0
FSMRA8JH 13.26 mm 2-1825027-3
FSM100 1.6 N 4.3 mm THT bulk 1437565-2
FSM101 7.5 mm 1437565-3
FSM102 12 mm 1437565-4
FSM103 7.3 mm THT, square button 1437565-5
FSM104 - THT, right angle 1437565-6
FSM10, Sealed
FSM100SSM 1.6 N 4.3 mm SMT bulk 1571218-1
FSM100SSMTR tape and reel 1571218-3
FSM100S THT bulk 1571220-1
Product key Act Force Height Mounting Packaging Part number
FSM1MSJMPTR 2.2±.8 N 1.5 mm SMT/J w/loc tape and reel 1571908-1
FSM1MSJMTR SMT/J wo/loc 1571908-2
FSM2MSSMATR 2.5±.5 N 1.65 mm SMT wo/loc 1571895-1
FSM3MSJMPTR 2.2±.8 N SMT/J w/loc 1571910-1
FSM3MSJMTR SMT/J wo/loc 1571910-2
FSM3MSSMPTR SMT w/loc 1571909-1
FSM3MSSMTR SMT wo/loc 1571909-2
Product key Act Force Height Mounting Packaging Part number
FSMMSHPTR 1.6N 3.3 mm SMT, w/loc. pegs tape and reel 1977066-1
FSMMSHTR SMT, no pegs 1977067-1
Product key Act Force Height Mounting Packaging Part number
FSMCTTR 1.6 N 1.5 mm SMT tape and reel 8-1437565-0
FSMCTATR 2.6 N 8-1437565-1
Product key Act Force Height Mounting Packaging Part number
FSMLPUTR 1.6 N 0.5 mm SMT tape and reel 1825534-1
ASE2204 DPDT Ag THT 1825010-1
ASE22G04 Au 1825010-2
ASE22GL04 SMT/L 1825010-5
ASE22GS04 SMT/rev. L 1825010-7
ASE22L04 Ag SMT/L 1825010-6
ASE22S04 SMT/rev. L 1825010-8
ASE4204 4PDT THT 1-1825010-3
ASE42G04 Au 1-1825010-4
ASE42GL04 SMT/L 1-1825010-7
ASE42L04 Ag 1-1825010-8
ASE42S04 SMT/rev. L 2-1825010-0
ASE6204 6PDT THT 3-1825010-7
ASE62G04 Au 3-1825010-8
ASE62GL04 SMT/L 4-1825010-1
ASE62L04 Ag 4-1825010-2
ASE Side Actuator
ASE22R04 DPDT Ag THT 1825010-3
ASE22RG04 Au 1825010-4
ASE22RGS04 SMT/rev. L 1-1825010-1
ASE22RL04 Ag SMT/L 1-1825010-0
ASE22RS04 SMT/rev. L 1-1825010-2
ASE42R04 4PDT THT 1-1825010-5
ASE42RG04 Au 1-1825010-6
ASE42RGL04 SMT/L 2-1825010-1
ASE42RL04 Ag 2-1825010-2
ASE42RS04 SMT/rev. L 2-1825010-4
ASE43R04 4P3T THT 2-1825010-7
ASE43RG04 Au 2-1825010-8
ASE62R04 6PDT Ag 3-1825010-9
ASE62RG04 Au 4-1825010-0
ASE62RGL04 SMT/L 4-1825010-5
ASE62RL04 Ag 4-1825010-6
Product key Type Contact material Mounting Part number
ASF
ASF2204 DPDT Ag THT 1825011-1
ASF22G04 Au 1825011-2
ASF22GL04 SMT/L 1825011-5
ASF22GS04 SMT/rev. L 1825011-9
ASF22L04 Ag SMT/L 1825011-7
ASF22S04 SMT/rev. L 1-1825011-1
ASF4204 4PDT THT 2-1825011-1
ASF42G04 Au 2-1825011-2
ASF42GL04 SMT/L 2-1825011-5
ASF42L04 Ag 2-1825011-7
ASF42S04 SMT/rev. L 3-1825011-1
ASF6204 6PDT THT 6-1825011-1
ASF62G04 Au 6-1825011-2
ASF62GL04 SMT/L 6-1825011-5
ASF62L04 Ag 6-1825011-7
ASF62S04 SMT/rev. L 7-1825011-1
ASF Side Actuator
ASF22R04 DPDT Ag THT 1825011-3
ASF22RG04 Au 1825011-4
ASF22RGL04 SMT/L 1-1825011-3
ASF22RGS04 SMT/rev. L 1-1825011-7
ASF22RS04 Ag 1-1825011-9
ASF42R04 4PDT THT 2-1825011-3
ASF42RG04 Au 2-1825011-4
ASF42RGL04 SMT/L 3-1825011-3
ASF42RL04 Ag 3-1825011-5
ASF42STR04 SMT/rev. L 3-1825011-2
ASF62R04 6PDT THT 6-1825011-3
ASF62RG04 Au 6-1825011-4
ASF62RGL04 SMT/L 7-1825011-3
ASF62RGS04 SMT/rev. L 7-1825011-7
Product key Type Mounting Packaging Part number
S
S1EGPC04 1 Pole, On-Off-On THT bulk 5-1571005-2
S2EGPC04 2 Pole, On-Off-On 5-1571005-4
S Right Angle
S1EGRA04 1 Pole, On-Off-On THT bulk 5-1571006-2
S2EGRA04 2 Pole, On-Off-On 5-1571006-4
SE Sealed
SE1EGPC04 1 Pole, On-Off-On THT bulk 1825032-2
SE2EGPC04 2 Pole, On-Off-On 1825032-4
SE1GSMTTR04 1 Pole, On-Off SMT tape and reel 5-1571004-4
SE1EGSMTTR04 1 Pole, On-Off-On 5-1571004-5
SE Sealed Right Angle
SE1EGRA04 1 Pole, On-Off-On THT bulk 1825031-2
SE2EGRA04 2 Pole, On-Off-On 1825031-4
Product key Type Mounting Throw function Part number
STS121PC04 SPDT THT 1825159-1
STS1300PC04 SP3T common pin 2 1825161-1
STS131PC04 1825159-2
STS1400PC04 SP4T common pin 3 1825161-2
STS141PC04 1825159-3
STS151PC04 SP5T 1825159-4
STS161PC04 SP6T 1825159-5
STS220PC04 DPDT 1825163-1
STS2300PC04 DP3T common pin 2 1825164-1
STS230PC04 1825163-2
STS2400PC04 DP4T common pin 3 1825165-1
STS240PC04 1825163-3
STS250PC04 DP5T 1825163-4
STS260PC04 DP6T 1825163-5
Product key Type Positions Packaging Part number
TSS Single
TSS11DGPC04 SPDT On-None-On bulk 1571982-1
TSS11EGPC04 On-Off-On 1571982-4
TSS Single, Flush actuator
TSS11DG1PC04 SPDT On-None-On bulk 1571982-2
TSS11EG1PC04 On-Off-On 1571982-3
TSS Dual
TSS21KGPC04 DPST On-None-Off bulk 1571982-5
TSS21NGPC04 DPDT On-None-On 1571982-7
TSS21PGPC04 On-Off-On 1571982-9
TSS Dual, Flush actuator
TSS21NG1PC04 DPST On-None-Off bulk 1571982-6
TSS21PG1PC04 DPDT On-None-On 1571982-8
TSD21DDGPC04 On-Off-On 1825015-1
Product key Type Contact material Version Part number
MSS120004 SPDT Ag vertical 1825257-1
MSS1200G04 Au 1825257-2
MSS1200R04 Ag right angle 1825258-1
MSS1200RG04 Au 1825258-2
MSS130004 SP3T Ag vertical 1825259-1
MSS1300G04 Au 1825259-2
MSS1300R04 Ag right angle 1825260-1
MSS1300RG04 Au 1825260-2
MSS140004 SP4T Ag vertical 1571423-2
MSS222504 DPDT 1825262-1
MSS2225G04 Au 1825262-2
MSS420004 4PDT Ag 1825264-1
MSS4200G04 Au 1825264-2
MSS4200R04 Ag right angle 1825265-1
MSS4200RG04 Au 1825265-2
MSS430004 4P3T Ag vertical 1825267-1
MSS4300G04 Au 1825267-2
MSS4300R04 Ag right angle 1825268-1
MSS4300RG04 Au 1825268-2
MSS620004 6PDT Ag vertical 1825271-1
MSS6200G04 Au 1825271-2
MSS635004 6P3T Ag 1825273-1
MSS6350R04 right angle 1825274-1
Product key Type Contact material Positions Part number
MSSA111DG SPDT Au On-None-On 2-1437580-9
MSSA111EG On-Off-On 3-1437580-0
MSSA114D Ag On-None-On 3-1437580-1
MSSA114E On-Off-On 3-1437580-2
MSSA211NG DPDT Au On-None-On 4-1437580-9
MSSA211N Ag 5-1437580-2
Product key Type Contact material Style Part number
SSJ1204 SPDT Ag vertical 1825280-1
SSJ12R04 right angle 1825282-1
SSJ1304 SP3T vertical 1825283-1
Product key Type Contact material Style Part number
SSA1204 SPDT Ag vertical 1571981-1
SSA12G04 Au 1571981-2
SSA2204 DPDT Ag 1571981-3
SSA22G04 Au 1571981-4
Product key Type Mounting Style Part number
SLS121PC04 SPDT THT vertical 1825115-1
SLS121RA04 right angle 1825116-1
SLS131PC04 SP3T vertical 1825117-1
SLS131RA04 right angle 1825118-1
SLS141PC04 SP4T vertical 1825119-1
SLS141RA04 right angle 1825120-1
SLS151PC04 SP5T vertical 1825121-1
SLS151RA04 right angle 1825122-1
SLS220PC04 DPDT vertical 1825080-1
SLS230PC04 DP3T 1825080-2
SLS240PC04 DP4T 1825080-3
SLS250PC04 DP5T 1825080-4
SLS260PC04 DP6T 1825080-5
Product key Type Contact material Positions Part number
MHS
MHS12204 SPDT Ag On-None-On 1825255-1
MHS122G04 Au 1825255-2
MHS12304 Ag On-Off-On 1825255-5
MHS13304 SP3T On-On-On 1825255-7
MHS133G04 Au 1825255-8
MHS22204 DPDT Ag On-None-On 1825289-1
MHS222G04 Au 1825289-2
MHS22304 Ag On-Off-On 1825289-5
MHS223G04 Au 1825289-6
MHS23304 DP3T Ag On-On-On 1825289-8
MHS233G04 Au 1825289-9
MHS Right Angle
MHS122GRA04 SPDT Au On-None-On 1825256-4
MHS122RA04 Ag 1825256-1
MHS123GRA04 Au On-Off-On 1825256-5
MHS123RA04 Ag 1825256-2
MHS133GRA04 SP3T Au On-On-On 1825256-6
MHS133RA04 Ag 1825256-3
MHS222GRA04 DPDT Au On-None-On 1825290-4
MHS222RA04 Ag 1825290-1
MHS223GRA04 Au On-Off-On 1825290-5
MHS223RA04 Ag 1825290-2
MHS233GRA04 DP3T Au On-On-On 1825290-6
MHS233RA04 Ag 1825290-3
Product key Type Mounting Packaging Part number
MLL1200S SPDT SMT tube 1437575-1
MLL1200STR tape and reel 1437575-2
Product key Type Contact material Positions Part number
TST
TST11DGPC1D04 1 Pole, PCB Ag On-None-On 1825455-1
TST, Right Angle
TST11DGRA1D04 1 Pole Ag On-None-On 1825455-3
TST11DGVRA1D04 1 Pole Vertical r.a. 1825455-4
Product key Type Contact material Positions Part number
TT
TT13A2T04 1 Pole, Wire Lugs Ag On-None-Off 1825222-2
TT13D2T04 On-None-On 1825222-3
TT13E2T04 On-Off-On 1825222-4
TT23K2T04 2 Pole, Wire Lugs On-None-Off 1825222-6
TT23N2T04 On-None-On 1825222-7
TT11AGPC104 1 Pole, PCB On-None-Off 1825219-2
TT11DGPC104 On-None-On 1825219-3
TT11EGPC104 On-Off-On 1825219-6
TT21KGPC104 2 Pole, PCB On-None-Off 1-1825219-0
TT21NGPC104 On-None-On 1-1825219-1
TT Right Angle
TT11DGVRA104 1 Pole, PCB Ag On-None-On 1825219-5
TT11EGVRA104 2 Pole, PCB On-Off-On 1825219-9
Product key Type Contact material Positions Part number
Gemini A
A101SYCB04 1 Pole, PCB Au On - On 4-1825136-4
A101SYCQ04 Ag 4-1825136-5
A101SYZB04 1 Pole, Wire Lug Au 4-1825136-8
A101SYZQ04 Ag 4-1825136-9
A103SYCB04 1 Pole, PCB Au On - Off - On 1-1825137-5
A103SYCQ04 Ag 1-1825137-6
A103SYZB04 1 Pole, Wire Lug Au 1-1825137-9
A103SYZQ04 Ag 2-1825137-0
A201SYCB04 2 Pole, PCB Au On - On 2-1825138-4
A201SYCQ04 Ag 2-1825138-5
A201SYZB04 2 Pole, Wire Lug Au 2-1825138-7
A201SYZQ04 Ag 2-1825138-8
A203SYCB04 2 Pole, PCB Au On - Off - On 1825139-8
A203SYCQ04 Ag 1825139-9
A203SYZQ04 2 Pole, Wire Lug 1-1825139-0
A211SYCQ04 2 Pole, PCB On - On - On 3-1825139-7
A211SYZQ04 2 Pole, Wire Lug 3-1825139-9
Gemini A, Right Angle
A101SYAV2B04 1 Pole, PCB Au On - On 1825136-8
A103SYAV2B04 On - Off - On 2-1825136-5
A103SYAV2Q04 Ag 1-1825137-4
Product key Type Contact material Positions Part number
Gemini AE
AE101SD1CB04 1 Pole, PCB Au On-On 2-1825142-0
AE101SD1CQ04 Ag 2-1825142-1
AE103SD1CB04 Au On-Off-On 3-1825142-0
AE103SD1CQ04 Ag 3-1825142-1
AE201SD1CB04 2 Pole, PCB Au On-On 1-1825143-0
AE201SD1CQ04 Ag 1-1825143-1
AE203SD1CB04 Au On-Off-On 1-1825143-9
Gemini AE, Right Angle
AE101SD1AV2B04 1 Pole, PCB Au On-On 1-1825142-8
AE101SD1AV2Q04 Ag 1-1825142-9
AE103SD1AV2B04 Au On-Off-On 2-1825142-9
AE201SD1AV2B04 2 Pole, PCB On-On 1825143-9
AE203SD1AV2B04 On-Off-On 1-1825143-7
AE203SD1AV2Q04 Ag 1-1825143-8
MTA306D04 3PDT, wire lug Ag gold flash On-None-On 3-1571920-0
MTA306DPC04 3PDT, THT 3-1571920-1
MTA306E04 3PDT, wire lug On-Off-On 3-1571920-2
MTA306EPC04 3PDT, THT 3-1571920-3
MTA406N04 4PDT, wire lug On-None-On 3-1571920-8
MTA406NPC04 4PDT, THT 3-1571920-9
MTA406P04 4PDT, wire lug On-Off-On 4-1571920-0
MTA406PPC04 4PDT, THT 4-1571920-3
MTA Right Angle
MTA8106DVRA04 SPDT, THT Ag gold flash On-None-On 1571922-4
MTA8106EVRA04 On-Off-On 1571922-8
MTE (Sealed)
MTE306D04 3PDT, wire lug Ag gold flash On-None-On 1-1571924-6
MTE306E04 On-Off-On 1-1571924-7
MTE406N04 4PDT, wire lug On-None-On 1-1571924-8
MTE406P04 On-Off-On 1-1571924-9
Product key Type Contact material Position Part number
AWTD1504 1 pole, tab Ag On-On 7-6437630-0
AWTN1504 2 pole, tab 7-6437630-2
AWTR1504 On-(On) 5-6437630-0
AWTS1504 (On)-Off-(On) 1-6437630-1
AWTT1504 On-Off-(On) 1-6437630-0
Product key Type Contact material Position Part number
FTD0904 1 pole, std. Ag On-On 2-6437630-0
FTD09G04 Au 3-6437630-4
FTD5904 1 pole, locking Ag 1-6437630-5
FTD59G04 Au 4-6437630-0
FTD7904 1 pole, Long Ag 5-6437630-3
FTE0904 1 pole, std. On-Off-On 6-6437630-2
FTH0904 On-Off-(On) 4-6437630-8
FTN0904 2 pole, std. On-On 4-6437630-2
FTN5904 2 pole, locking 3-6437630-9
FTN59G04 Au 6-6437630-1
FTP0904 2 pole, std. Ag On-Off-On 4-6437630-6
FTPA0904 On-On-On 4-6437630-5
FTS0904 (On)-Off-(On) 4-6437630-3
F4TN0904 4 pole, std. 3-6437630-5
TPA11CGPC004 SPST, THT Au Rnd. no bushing 1825096-1
TPA11FGPC004 SPDT, THT 1825096-7
TPA, Right Angle
TPA11CGRA004 SPST, THT Au Rnd. no bushing 1825096-4
TPA11FGRA004 SPDT, THT 1-1825096-0
TPB
TPB11CGPC004 SPST, THT Au Rnd. 0.188”, 1825097-1
TPB11FGPC004 SPDT, THT unthreaded 1825097-9
TPB21MGPC004 DPST, THT 1-1825097-7
TPB, Right Angle
TPB11CGRA004 SPST, THT Au Rnd. 0.188”, 1825097-6
TPB11FGRA004 SPDT, THT unthreaded 1-1825097-1
MPA106D04 SPDT Wire Lug Push On/ Push Off 1825040-1
MPA106DPC04 THT 1825040-3
MPA106F04 Wire Lug Momentary 1825040-2
MPA106FPC04 THT 1825040-4
MPA206N04 DPDT Wire Lug Push On/ Push Off 1825040-5
MPA206NPC04 THT 1825040-6
MPA206R04 Wire Lug Momentary 1825040-7
MPA206RPC04 THT 1825040-8
MPA306D04 3PDT Wire Lug Push On/ Push Off 1825040-9
MPA306F04 Momentary 1-1825040-0
MPA406N04 4PDT Push On/ Push Off 1-1825040-1
MPA406R04 Momentary 1-1825040-2
MPE (Splash proof)
MPE106D04 SPDT Wire Lug Push On/ Push Off 1825041-1
MPE106F04 Momentary 1825041-2
MPE206N04 DPDT Push On/ Push Off 1825041-3
MPE206R04 Momentary 1825041-4
MPE306D04 3PDT Push On/ Push Off 1825041-5
MPE306F04 Momentary 1825041-6
MPE406N04 4PDT Push On/ Push Off 1825041-7
MPE406R04 Momentary 1825041-8
MPG
MPG106D04 SPDT Wire Lug Push On/ Push Off 1825042-1
MPG106F04 Momentary 1825042-3
MPG206N04 DPDT Push On/ Push Off 1825042-5
MPG206NPC04 THT 1825042-6
MPG206R04 Wire Lug Momentary 1825042-7
MPG206RPC04 THT 1825042-8
MPG306D04 3PDT Wire Lug Push On/ Push Off 1825042-9
MPG306F04 Momentary 1-1825042-0
MPG406N04 4PDT Push On/ Push Off 1-1825042-1
MPG406R04 Momentary 1-1825042-2
MP16DTCOLG spade terminal SPDT 16 A pin plunger 2.0 N / 0.5 N 1-1478607-1
MP16DTCNLD normal lever 1-1478607-3
MP16DTCNRD normal roller 1-1478607-6
MP16DTCSMD simulator lever 1-1478607-7
Product key Terminals Contacts Actuator Operating/Release Part number
SP5DTBOLE PCB SPDT 5 A pin plunger 1.5 N / 0.2 N 1-1478601-1
SP5DTBNLC normal lever 1-1478601-2
SP5DTBNRD normal roller 1-1478601-4
SP5DTBSMA simulator lever 1-1478601-5
Product key Terminals Contacts Actuator Operating/Release Part number
UP3DTANLA04 PCB SPDT normal lever 0.5 N / 0.08 N 1-1825043-5
UP3DTAOLA04 3A pin plunger 1.5 N / 0.2 N 1-1825043-3
UP01DTANLA04 SPDT normal lever 0.5 N / 0.08 N 1825043-3
UP01DTAOLA04 0.1A pin plunger 1.5 N / 0.2 N 1825043-1
PRASA1-16F-BB000 On-Off, opaque black not applicable 1571076-9
PRASA1-16F-BB0BW 0 - , white printing 1-1571076-0
PRASA1-16F-BB0CW 0 l , white printing 1-1571076-1
PRASA1-16F-BR000 red not applicable 6-1571076-5
PRASA1-16F-BB0HW black ON OFF, white pr. 2-1571076-0
PRASD1-16F-BB000 not applicable 1571079-4
PRASD1-16F-BB0DW - = , white printing 1571079-5
PRASD1-16F-BB0EW l ll , white printing 1571079-6
PRASD3-16F-BB000 On-Off-On, opaque not applicable 1571079-7
PRASD3-16F-BB0FW - 0 =, white printing 1571079-8
PRASD3-16F-BB0GW l 0 ll, white printing 1571079-9
PRASD2-16F-BB000 On-(On), opaque not applicable 1-1571079-0
PRASD2-16F-BB0DW - = , white printing 1-1571079-1
PRASD2-16F-BB0EW l ll , white printing 1-1571079-2
PRASD4-16F-BB000 On-Off-(On), opaque not applicable 1-1571079-3
PRASD4-16F-BB0FW - 0 =, white printing 1-1571079-4
PRASD4-16F-BB0GW l 0 ll, white printing 1-1571079-5
PRA Series, 13.0x19.2mm panel cutout, 6A double pole
PRADA1-12F-BB000 On-Off, opaque black not applicable 1977068-1
PRADA1-12F-BB0BW 0 - , white printing 1977068-2
PRADA1-12F-BB0CW 0 l , white printing 1977068-3
PRADA1-12F-BR000 red not applicable 1977068-4
PRADA1-12F-BR0BW 0 - , white printing 1977068-5
PRADD1-12F-BB000 black not applicable 1977069-1
PRADD1-12F-BB0DW - = , white printing 1977069-2
PRADD1-12F-BB0EW l ll , white printing 1977069-3
PRADD3-12F-BB000 On-Off-On, opaque not applicable 1977069-4
PRADD3-12F-BB0FW - 0 =, white printing 1977069-5
PRADD3-12F-BB0GW l 0 ll, white printing 1977069-6
PRADD2-12F-BB000 1977069-7
PRADD2-12F-BB0DW On-(On), opaque - = , white printing 1977069-8
PRADD2-12F-BB0EW l ll , white printing 1977069-9
PRADD4-12F-BB000 On-Off-(On), opaque not applicable 1-1977069-0
PRADD4-12F-BB0FW - 0 =, white printing 1-1977069-1
PRADD4-12F-BB0GW l 0 ll, white printing 1-1977069-2
Product key Switch function Rocker color Text pattern Part number
PREDA1-07F-BB000 On-Off, opaque black not applicable 1634200-1
PREDA1-07F-BB0BW 0 - , white printing 1634200-2
PREDA1-07F-BB0CW 0 l , white printing 1634200-3
PREDB1-07F-BR000 On-Off, illuminated red not applicable 1634200-7
PREDB1-07F-BG000 green 1634200-9
PREDD1-07F-BB000 On-On, opaque black 1-1634200-1
PREDD1-07F-BB0DW l ll , white printing 1-1634200-2
PREDD1-07F-BB0EW - = , white printing 1-1634200-3
PREDD3-07F-BB0FW On-Off-On, opaque l 0 ll, white printing 1-1634200-7
PREDD3-07F-BB0GW - 0 =, white printing 1-1634200-8
PREDD4-07F-BB000 On-Off-(On), opaque not applicable 2-1634200-1
PREDD4-07F-BB0FW l 0 ll, white printing 2-1634200-2
PREDD4-07F-BB0GW - 0 =, white printing 2-1634200-3
PREDD5-07F-BB000 (On)-Off-(On), opaque not applicable 2-1634200-4
PREDD5-07F-BB0FW l 0 ll, white printing 2-1634200-5
PREDD5-07F-BB0GW - 0 =, white printing 2-1634200-6
Product key Switch function Rocker color Text pattern Part number
PRCSA1-20F-BB0BW On-Off, opaque black 0 - , white printing 1571095-2
PRCSD1-20F-BB0DW On-On, opaque - = , white printing 1571100-2
PRCDA1-20F-BB0BW On-Off, opaque 0 - , white printing 1571102-2
PRCDD1-20F-BB0DW On-On, opaque - = , white printing 1571099-2
PRCSA1-20F-BB0BW On-Off, opaque black 0 - , white printing 1571095-2
PRCSD1-20F-BB0DW On-On, opaque - = , white printing 1571100-2
PRCDA1-20F-BB0BW On-Off, opaque 0 - , white printing 1571102-2
PRCDD1-20F-BB0DW On-On, opaque - = , white printing 1571099-2
PREDA1-07F-BB000 On-Off, opaque black not applicable 1634200-1
PREDA1-07F-BB0BW 0 - , white printing 1634200-2
PREDA1-07F-BB0CW 0 l , white printing 1634200-3
PREDB1-07F-BR000 On-Off, illuminated red not applicable 1634200-7
PREDB1-07F-BG000 green 1634200-9
PREDD1-07F-BB000 On-On, opaque black 1-1634200-1
PREDD1-07F-BB0DW l ll , white printing 1-1634200-2
PREDD1-07F-BB0EW - = , white printing 1-1634200-3
PREDD3-07F-BB0FW On-Off-On, opaque l 0 ll, white printing 1-1634200-7
PREDD3-07F-BB0GW - 0 =, white printing 1-1634200-8
PREDD4-07F-BB000 On-Off-(On), opaque not applicable 2-1634200-1
PREDD4-07F-BB0FW l 0 ll, white printing 2-1634200-2
PREDD4-07F-BB0GW - 0 =, white printing 2-1634200-3
PREDD5-07F-BB000 (On)-Off-(On), opaque not applicable 2-1634200-4
PREDD5-07F-BB0FW l 0 ll, white printing 2-1634200-5
PREDD5-07F-BB0GW - 0 =, white printing 2-1634200-6
PRGSB1-16F-BG000 On-Off, illuminated green not applicable 1634202-6
PRGSB1-16F-BR000 red 1634202-5
PRGSA1-16F-BR000 On-Off, opaque 1634202-4
PRGSA1-16F-BB0BW black 0 - , white printing 1634202-3
PRGSA1-16F-BB0AW , white printing 1634202-2
PRGSA1-16F-BB000 not applicable 1634202-1
￥
% Tyco Electronics Austria GmbH 2008. All Rights Reserved.
All technical data listed is for description purposes only and does
not guarantee characteristics. All drawings, photos and
descriptions are subject to change without prior notice.
We are not able to guarantee that the specified circuits,
descriptions and tables are not covered by rights of third parties.
Terms of delivery and rights to change design reserved.
Product key Switch function Rocker color Text pattern Part number
P
