Arcol HS15 系列 绕线 面板安装电阻器, 轴向接端, 铝壳封装
15W 铝封装线绕功率电阻器，HS 系列
15W 铝封装功率电阻器，按照 MIL 18546 和 IEC 115 的要求制造，且符合 RoHS 标准 。
实现额定功率的尺寸小
线绕结构化高脉冲能力
25°C 时功率 25 ° C 时，8W 无散热片
25°C 时，15W（带有 5.1°C/W 散热器）
电阻容差 ±5%
温度系数 <1KΩ ±100ppm/°C,>1KΩ ±25ppm/°C
工作温度 - 55 ° C → +200 ° C
极限元件电压 265V 直流/V 交流有效值
绝缘电阻 10000MΩ
长度 36.5 mm
宽度 21.0 mm
高度 11.0 mm
重量 7 g
注
为了实现此功率电阻器的性能额定值，其设计为直接安装在适当匹配的散热器上，并使用导热膏安装。
铝封装线绕 - 5 到 600W
