Limit and Enclosed Switches HDLS Series Modification and Replacement Parts Honeywell 1 Sensing and Control 1 1-800-537-6945 USA 1 F1-815-235-6847 International 1 1-800-737-3360 Canada A49 Non plug-in type Plug-in type REPLACEMENT WOBBLE ACTUATORS Catalog Listing Delrin Spring Cat Coil Rod Wire Cable Whisker Spring LSZ4009 LSZ4010 LSZ4011 LSZ4012* LSZ4014 *51⁄2 inch long. For 71⁄2N length, order LSZ4013. MICRO SWITCH conduit sealing packets can be used with limit or enclosed switches. This includes the HDLS, Compact LS, ML, E6, V6, BAF1 or OP series switches. The conduit sealing packets are not suitable for use with explosion-proof switches. PLUG IN RECEPTACLES Type Catalog Listing Single-Pole LSZ4001 Double-Pole LSZ4002 3⁄4 in. Conduit Double-Pole LSZ4006 1⁄2 in. Conduit Single-Pole LSZ4015 Manifold Mount Double-Pole LSZ4016 Manifold Mount ADAPTER PLATES These adapter plates enable HDLS plug-in switches to retrofit 200LS series (singlepole) and 300LS series (double-pole) plugin switches. Catalog Type Listing Adapts 200LS series LSZ4003 mounting to accept HDLS Adapts 300LS series LSZ4004 mounting to accept HDLS INDICATOR LIGHTS/SEAL RING Type Catalog Listing 120V LSZ4007 240V LSZ4008 ADJUSTING TOOL KIT This tool kit is used if readjustment of switches is necessary when heads and/or contact blocks are replaced. Catalog Listing LSZ4005 REPLACEMENT LEVERS To order replacement levers, specify the same part number that is metal stamped on either the lever or lever hub. For a complete list of HDLS replacment parts, refer to the charts on the following pages. CONDUIT SEALING PACKETS Catalog Listing Packet Cable O.D. Inches 2PA6 .400N - .435N 2PA16 .435N - .470N 2PA1 .530N - .570N LIQUID TIGHT CONDUIT FITTING 2PA17 .170" - .470" ½ NPT 2PA19 .450" - .709" ¾ NPT Limit/Enclosed Limit and Enclosed Switches HDLS Series Replacement Parts A50 Honeywell 1 Sensing and Control 1 1-800-537-6945 USA 1 F1-815-235-6847 International 1 1-800-737-3360 Canada For low temperature or high temperature options, refer to example in LSA1A block. PLUG-IN TYPE 12345 Catalog Complete Plug-in Listing* Plug-in Unit Base Operating Contact On Switch Less Base Receptacle Head Block Actuator Nameplate Receptacle Only Only† Only Only Std. LSA1A LSZ7A1A LSZ4001 LSZ1A LSZ3A Low Temp. LSYAB1A LSZ7YAB1A LSZ4001 LSZ1AB LSZ3A High Temp. LSYAC1A LSZ7YAC1A LSZ4001 LSZ1AC LSZ3A LSA5A LSZ7A5A LSZ4001 LSZ1A LSZ3A LSA8A LSZ7A8A LSZ4001 LSZ1A LSZ3A LSA1J LSZ7A1J LSZ4001 LSZ1A LSZ3J LSA2B LSZ7A2B LSZ4002 LSZ1A LSZ3B LSA6B LSZ7A6B LSZ4006 LSZ1A LSZ3B LSB1A LSZ7B1A LSZ4001 LSZ1B LSZ3A LSB1J LSZ7B1J LSZ4001 LSZ1B LSZ3J LSB5A LSZ7B5A LSZ4001 LSZ1B LSZ3A LSB8A LSZ7B8A LSZ4001 LSZ1B LSZ3A LSB2B LSZ7B2B LSZ4002 LSZ1B LSZ3B LSB6B LSZ7B6B LSZ4006 LSZ1B LSZ3B LSC1A LSZ7C1A LSZ4001 LSZ1C LSZ3A LSC1J LSZ7C3J LSZ4001 LSZ1C LSZ3J LSC5A LSZ7C5A LSZ4001 LSZ1C LSZ3A LSC8A LSZ7C8A LSZ4001 LSZ1C LSZ3A LSC2B LSZ7C2B LSZ4002 LSZ1C LSZ3B LSC6B LSZ7C6B LSZ4006 LSZ1C LSZ3B LSD1A LSZ7D1A LSZ4001 LSZ1D LSZ3A LSD1J LSZ7D1J LSZ4001 LSZ1D LSZ3J LSD2B LSZ7D2B LSZ4002 LSZ1D LSZ3B LSD5A LSZ7D5A LSZ4001 LSZ1D LSZ3A LSD8A LSZ7D8A LSZ4001 LSZ1D LSZ3A LSD6B LSZ7D6B LSZ4006 LSZ1D LSZ3B LSE1A LSZ7E1A LSZ4001 LSZ1E LSZ3A *Only partial listings are shown and necessary to determine replacement parts catalog listing. The listings with -7A, -7M, -7N, -8A, -8B and -8C are complete catalog listings. Note: Complete units consist of Columns 1 and 2. †For low temperature replacement heads add B. Example LSZ1AB. For fluorocarbon seal replacement heads add C. Example LSZ1AC. Limit and Enclosed Switches HDLS Series Replacement Parts Honeywell 1 Sensing and Control 1 1-800-537-6945 USA 1 F1-815-235-6847 International 1 1-800-737-3360 Canada A51 PLUG-IN TYPE (Continued) 1 2345 Catalog Complete Plug-in Listing* Plug-in Unit Base Operating Contact On Switch Less Base Receptacle Head Block Actuator Nameplate Receptacle Only Only† Only Only LSE1J LSZ7E1J LSZ4001 LSZ1E LSZ3J LSE2B LSZ7E2B LSZ4002 LSZ1E LSZ3B LSE5A LSZ7E5A LSZ4001 LSZ1E LSZ3A LSE8A LSZ7E8A LSZ4001 LSZ1E LSZ3A LSE6B LSZ7E6B LSZ4006 LSZ1E LSZ3B LSF1A LSZ7F1A LSZ4001 LSZ1F LSZ3A LSF1J LSZ7F1J LSZ4001 LSZ1F LSZ3J LSF2B LSZ7F2B LSZ4002 LSZ1F LSZ3B LSF5A LSZ7F5A LSZ4001 LSZ1F LSZ3A LSF8A LSZ7F8A LSZ4001 LSZ1F LSZ3A LSF6B LSZ7F6B LSZ4006 LSZ1F LSZ3B LSG1A LSZ7G1A LSZ4001 LSZ1G LSG5A LSZ7G5A LSZ4001 LSZ1G LSG8A LSZ7G8A LSZ4001 LSZ1G LSG2B LSZ7G2B LSZ4002 LSZ1G LSG6B LSZ7G6B LSZ4006 LSZ1G LSH1A LSZ7H1A LSZ4001 LSZ1H LSZ3A LSH2B LSZ7H2B LSZ4002 LSZ1H LSZ3B LSH6B LSZ7H6B LSZ4006 LSZ1H LSZ3B LSH5A LSZ7H5A LSZ4001 LSZ1H LSZ3A LSH8A LSZ7H8A LSZ4001 LSZ1H LSZ3A LSJ1A-7A LSZ7J1A-7A LSZ4001 LSZ1JGA** LSZ3A LSZ4009 LSJ1A-7M LSZ7J1A-7M LSZ4001 LSZ1JGM** LSZ3A LSZ4010 *Only partial listings are shown and necessary to determine replacement parts catalog listing. The listings with -7A, -7M, -7N, -8A, -8B and -8C are complete catalog listings. **Includes actuator Note: Complete units consist of Columns 1 and 2. † For low temperature replacement heads add B. Example LSZ1AB. For fluorocarbon seal replacement heads add C. Example LSZ1AC. Limit/Enclosed Limit and Enclosed Switches HDLS Series Replacement Parts A52 Honeywell 1 Sensing and Control 1 1-800-537-6945 USA 1 F1-815-235-6847 International 1 1-800-737-3360 Canada PLUG-IN TYPE (Continued) 1 2345 Catalog Complete Plug-in Listing* Plug-in Unit Base Operating Contact On Switch Less Base Receptacle Head and Block Actuator Nameplate Receptacle Only Actuator‡ Only Only LSJ5A-7M LSZ7J5A-7M LSZ4001 LSZ1JGM LSZ3A LSZ4010 LSJ8A-7M LSZ7J8A-7M LSZ4001 LSZ1JGM LSZ3A LSZ4010 LSJ2B-7A LSZ7J2B-7A LSZ4002 LSZ1JGM LSZ3B LSZ4009 LSJ2B-7M LSZ7J2B-7M LSZ4002 LSZ1JGM LSZ3B LSZ4010 LSJ6B-7M LSZ7J6B-7M LSZ4006 LSZ1JGM LSZ3B LSZ4010 LSJ5A-7A LSZ7J5A-7A LSZ4001 LSZ1JGA LSZ3A LSZ4009 LSJ8A-7A LSZ7J8A-7A LSZ4001 LSZ1JGA LSZ3A LSZ4009 LSJ6B-7A LSZ7J6B-7A LSZ4006 LSZ1JGA LSZ3B LSZ4009 LSJ1A-7N LSZJ1A-7N LSZ4001 LSZ1JGN LSZ3A LSZ4011 LSJ1J-7N LSZ7J1J-7N LSZ4001 LSZ1JGN LSZ3J LSZ4011 LSJ5A-7N LSZ7J5A-7N LSZ4001 LSZ1JGN LSZ3A LSZ4011 LSJ8A-7N LSZ7J8A-7N LSZ4001 LSZ1JGN LSZ3A LSZ4011 LSJ2B-7N LSZ7J2B-7N LSZ4002 LSZ1JGN LSZ3B LSZ4011 LSJ6B-7N LSZ7J6B-7N LSZ4006 LSZ1JGN LSZ3B LSZ4011 LSK1A-8A LSZ7K1A-8A LSZ4001 LSZ1KHA LSZ3A LSZ4012 LSK1J-8A LSZ7K1J-8A LSZ4001 LSZ1KHA LSZ3J LSZ4012 LSK2B-8A LSZ7K2B-8A LSZ4002 LSZ1KHA LSZ3B LSZ4012 LSK5A-8A LSZ7K5A-8A LSZ4001 LSZ1KHA LSZ3A LSZ4012 LSK8A-8A LSZ7K8A-8A LSZ4001 LSZ1KHA LSZ3A LSZ4012 LSK6B-8A LSZ7K6B-8A LSZ4006 LSZ1KHA LSZ3B LSZ4012 LSK1A-8C LSZ7K1A-8C LSZ4001 LSZ1KHC LSZ3A LSZ4014 LSK1A-8B LSZ7K1A-8B LSZ4001 LSZ1KHB LSZ3A LSZ4013 LSK5A-8C LSZ7K5A-8C LSZ4001 LSZ1KHC LSZ3A LSZ4014 LSK8A-8C LSZ7K8A-8C LSZ4001 LSZ1KHC LSZ3A LSZ4014 LSK2B-8C LSZ7K2B-8C LSZ4002 LSZ1KHC LSZ3B LSZ4014 LSK6B-8C LSZ7K6B-8C LSZ4006 LSZ1KHC LSZ3B LSZ4014 *Only partial listings are shown and necessary to determine replacement parts catalog listing. The listings with -7A, -7M, -7N, -8A, -8B and -8C are complete catalog listings. Note: Complete units consist of Columns 1 and 2. ‡ For low temperature replacement head and actuators add B between the fifth and sixth characters. Example: LSZ1KBHA. For fluorocarbon seals add C. Example LSZ1KCHA. Limit and Enclosed Switches HDLS Series Replacement Parts Honeywell 1 Sensing and Control 1 1-800-537-6945 USA 1 F1-815-235-6847 International 1 1-800-737-3360 Canada A53 PLUG-IN TYPE (Continued) 1 2345 Catalog Complete Plug-in Listing* Plug-in Unit Base Operating Contact On Switch Less Base Receptacle Head Block Actuator Nameplate Receptacle Only Only† Only Only LSL2C LSZ7L2C LSZ4002 LSZ1L LSZ3C LSL6C LSZ7L6C LSZ4006 LSZ1L LSZ3C LSM2D LSZ7M2D LSZ4002 LSZ1M LSZ3C LSM6D LSZ7M6D LSZ4006 LSZ1M LSZ3C LSN1A LSZ7N1A LSZ4001 LSZ1N LSN2B LSZ7N2B LSZ4002 LSZ1N LSN5A LSZ7N5A LSZ4001 LSZ1N LSN8A LSZ7N8A LSZ4001 LSZ1N LSN6B LSZ7N6B LSZ4006 LSZ1N LSP1A LSZ7P1A LSZ4001 LSZ1P LSZ3A LSP1J LSZ7P1J LSZ4001 LSZ1P LSZ3J LSP2B LSZ7P2B LSZ4002 LSZ1P LSZ3B LSP5A LSZ7P5A LSZ4001 LSZ1P LSZ3A LSP8A LSZ7P8A LSZ4001 LSZ1P LSZ3A LSP6B LSZ7P6B LSZ4006 LSZ1P LSZ3B LSR1A LSZ7R1A LSZ4001 LSZ1R LSZ3A LSR2B LSZ7R2B LSZ4002 LSZ1R LSZ3B LSR6B LSZ7R6B LSZ4006 LSZ1R LSZ3B LSR5A LSZ7R5A LSZ4001 LSZ1R LSZ3A *Only partial listings are shown and necessary to determine replacement parts catalog listing. The listings with -7A, -7M, -7N, -8A, -8B and -8C are complete catalog listings. Note: Complete units consist of Columns 1 and 2. † For low temperature replacement heads add B. Example LSZ1AB. For fluorocarbon seal replacement heads add C. Example LSZ1AC. Limit/Enclosed Limit and Enclosed Switches HDLS Series Replacement Parts A54 Honeywell 1 Sensing and Control 1 1-800-537-6945 USA 1 F1-815-235-6847 International 1 1-800-737-3360 Canada PLUG-IN TYPE (Continued) 1 2345 Catalog Complete Plug-in Listing* Plug-in Unit Base Operating Contact On Switch Less Base Receptacle Head Block Actuator Nameplate Receptacle Only Only† Only Only LSR8A LSZ7R8A LSZ4001 LSZ1R LSZ3A LSS1H LSZ7S1H LSZ4001 LSZ1S LSZ3H LSU1A LSZ7U1A LSZ4001 LSZ1U LSZ3A LST1H LSZ7T1H LSZ4001 LSZ1T LSZ3H LSU5A LSZ7U5A LSZ4001 LSZ1U LSZ3A LSV1A LSZ7V1A LSZ4001 LSZ1V LSZ3A LSV1J LSZ7V1J LSZ4001 LSZ1V LSZ3J LSV5A LSZ7V5A LSZ4001 LSZ1V LSZ3A LSV8A LSZ7V8A LSZ4001 LSZ1V LSZ3A LSV2B LSZ7V2B LSZ4002 LSZ1V LSZ3B LSV6B LSZ7V6B LSZ4006 LSZ1V LSZ3B LSW1A LSZ7W1A LSZ4001 LSZ1W LSZ3A LSW1J LSZ7W1J LSZ4001 LSZ1W LSZ3J LSW5A LSZ7W5A LSZ4001 LSZ1W LSZ3A LSW8A LSZ7W8A LSZ4001 LSZ1W LSZ3A LSW2B LSZ7W2B LSZ4002 LSZ1W LSZ3B LSW6B LSZ7W6B LSZ4006 LSZ1W LSZ3B NON PLUG-IN TYPE (These parts will not form a complete switch) Catalog Listing* Operating Contact On Switch Head Block Actuator Nameplate Only† Only Only LSA3K LSZ1A LSZ3K LSA4L LSZ1A LSZ3L LSA7L LSZ1A LSZ3L LSB3K LSZ1B LSZ3K LSB4L LSZ1B LSZ3L LSB7L LSZ1B LSZ3L LSC3K LSZ1C LSZ3K LSC4L LSZ1C LSZ3L Catalog Listing* Operating Contact On Switch Head and Block Actuator Nameplate Actuator‡ Only Only LSJ7L-7A LSZ1JGA LSZ3L LSZ4009 LSJ7L-7M LSZ1JGM LSZ3L LSZ4010 LSJ4L-7N LSZ1JGN LSZ3L LSZ4011 LSJ7L-7N LSZ1JGN LSZ3L LSZ4011 LSK3K-8A LSZ1KHA LSZ3K LSZ4012 LSK4L-8A LSZ1KHA LSZ3L LSZ4012 LSK7L-8A LSZ1KHA LSZ3L LSZ4012 LSK3K-8C LSZ1KHC LSZ3K LSZ4014 *Only partial listings are shown and necessary to determine replacement parts catalog listing. The listings with -7A, -7M, -7N, -8A, -8B and -8C are complete catalog listings. Note: Complete units consist of Columns 1 and 2. ‡ For low temperature replacement head and actuators add B between the fifth and sixth characters. Example LSZ1KBHA. For fluorocarbon seals add C. Example LSZ1KCHA. Limit and Enclosed Switches HDLS Series Replacement Parts Honeywell 1 Sensing and Control 1 1-800-537-6945 USA 1 F1-815-235-6847 International 1 1-800-737-3360 Canada A55 NON PLUG-IN TYPE Catalog Listing* Operating Contact On Switch Head Block Actuator Nameplate Only† Only Only LSC7L LSZ1C LSZ3L LSD3K LSZ1D LSZ3K LSD4L LSZ1D LSZ3L LSD7L LSZ1D LSZ3L LSE3K LSZ1E LSZ3K LSE4L LSZ1E LSZ3L LSE7L LSZ1E LSZ3L LSF3K LSZ1F LSZ3K LSF4L LSZ1F LSZ3L LSF7L LSZ1F LSZ3L LSG3K LSZ1G LSG4L LSZ1G LSG7L LSZ1G LSH3K LSZ1H LSZ3K LSH4L LSZ1H LSZ3L LSH7L LSZ1H LSZ3L Catalog Listing* Operating Contact On Switch Head and Block Actuator Nameplate Actuator‡ Only Only LSJ3K-7A LSZ1JGA LSZ3K LSZ4009 LSJ3K-7M LSZ1JGM LSZ3K LSZ4010 LSJ3K-7N LSZ1JGN LSZ3K LSZ4011 LSJ4L-7A LSZ1JGA LSZ3L LSZ4009 LSJ4L-7M LSZ1JGM LSZ3L LSZ4010 LSK4L-8C LSZ1KHC LSZ3L LSZ4014 LSK7L-8C LSZ1KHC LSZ3L LSZ4014 ‡ For low temperature replacement head and actuators add B between the fifth and sixth characters. Example: LSZ1KBHA. For fluorocarbon seals add C. Example LSZ1KCHA. Catalog Listing* Operating Contact On Switch Head Block Actuator Nameplate Only† Only Only LSL4M LSZ1L LSZ3M LSL7M LSZ1L LSZ3M LSM4N LSZ1M LSZ3M LSM7N LSZ1M LSZ3M LSN3K LSZ1N LSN4L LSZ1N LSN7L LSZ1N LSP3K LSZ1P LSZ3K LSP4L LSZ1P LSZ3L LSP7L LSZ1P LSZ3L LSR3K LSZ1R LSZ3K LSR4L LSZ1R LSZ3L LSR7L LSZ1R LSZ3L LSV3K LSZ1V LSZ3K LSV4L LSZ1V LSZ3L LSV7L LSZ1V LSZ3L LSW3K LSZ1W LSZ3K LSW4L LSZ1W LSZ3L LSW7L LSZ1W LSZ3L REPLACEMENT PARTS FOR STAINLESS STEEL HDLS Listing Operating Head Contact Block LS2A3N LS2Z1A N/A LS2A4K LS2Z1A LSZ3K LS2A4L LS2Z1A LSZ3L LS2D4K LS2Z1D LSZ3K LS2D4L LS2Z1D LSZ3L LS2E4K LS2Z1E LSZ3K LS2E4L LS2Z1E LSZ3L LS2F4K LS2Z1F LSZ3K LS2F4L LS2Z1F LSZ3L LS2H3K LS2Z1H LSZ3K LS2H4K LS2Z1H LSZ3K LS2H4L LS2Z1H LSZ3L LS2M4N LS2Z1M LSZ3M LS2N3K LS2Z1N LSZ3K *Only partial listings are shown and necessary to determine replacement parts catalog listing. The listings with -7A, -7M, -7N, -8A, -8B and -8C are complete catalog listings. † For low temperature replacement heads add B. Example LSZ1AB. For fluorocarbon seal replacement heads add C. Example LSZ1AC.
