NKK Switches IS-ENG-KIT SmartSwitch Development Kits

NKK Switches IS-ENG-KIT SmartSwitch Development Kits are designed to accelerate the incorporation of SmartSwitch devices into real-world applications. IS-ENG-KIT switches provide a development platform for experimentation and design viability testing. These NKK Switches kits control up to two SmartSwitches or SmartDisplays or one OLED Rocker. Each kit provides 1M or 16M on-board NOR Flash memory for storing images, attributes, and other information. These dev kits also provide serial communication via USB and feature an auxiliary port with 7 I/O pins of microcontroller to control/sense other applications.

FEATURES

• Controls up to two SmartSwitches/SmartDisplays or one OLED Rocker

• 1M or 16M on-board NOR flash memory to store images, attributes or any other information

• Serial communication via USB (115.2K, 1 start bit, 8 bit, 1 stop bit)

• Auxiliary port with 7 I/O pins of microcontroller to control/sense other applications

• Stand alone or real time operation

• Preprogrammed for basic operation

• Reports via USB the switch closures, releases, timer expirations, and addresses of the images displayed

• Programmable to change the displayed images based on a switch actuation and user defined timers for stand-alone operation

• Schematics and firmware provided for user firmware customization

• User can program the engineering kits using The PICKIT3 and an adapter

• Kits come with 6-foot USB 2.0A to Mini-B cable (IS-USB1)

• Power Specs: Maximum 150mA at 5VDC

• Powered either by USB or by optional 5V power connection (.100¡± spacing)

• Windows-based software provided for communication
